Branson 2000Xc - Table 6.27 Code Output

100-412-234 REV. 06 151
6.10.35.2 Code Output
Table 6.27 Code Output
1 2 3 4 Where Definition
x x x x cccccccc@ is up to an 8-digit cycle count (Cycle Number)
x x x x hh:mm:ss@
is time of cycle in hours, minutes and seconds
(Time)
x x x x MM/DD/YY@ is date in month, day and year (Date)
x x x x Mode@
is weld mode (TIME, ENERGY, PKPWR,
COL. ABS, G DET)
x x x x tt.ttt@ length of ultrasonics in seconds (Act. Time)
x x x ppp.p@ is the peak power in percentage (Peak Power)
x x x eeeee@ is energy in joules (Act. Ener)
x x w.wwww@
is absolute distance at end of hold in inches or
mm (Total Absolute)
x x z.zzzz@
is collapse at end of weld in inches or mm
(Weld Collapse)
x x x.xxxx@
is collapse at end of hold in inches or mm
(Total Collapse)
x x FFF@
is the trigger force in pounds or Newton’s
(Trig. Force)
x AAA@
is set weld force or force A in pounds or
Newton’s (Set Force A)
x BBB@
is set force B in pounds or Newton’s or N/A
(Set Force B)
x x hhh@
is the weld force in pounds or Newton’s
(Weld Force)
x x x x sfff@
is frequency change (Hz) from start of
ultrasonics to end (Freq. Chg)
x x x x aaa@
is the set amplitude (or amplitude A) in
percentage (Set AmpA)
x x x bbb@
is the set amplitude B in percentage or N/A
(Set AmpB)
x x CRLF is the velocity in/sec or mm/sec (Act. Vel)
xxxx@
is either a space, tab or comma as selected by
user
x x x x IDID
is a 4 digit # assigned by “welder Addr” in
system configuration
