8.4 Power Supply Parts Lists
8.4.1 Replacement Parts
Table 8.3 Replacement Parts List for 2000Xc Power Supply
Component EDP Number
DC Power Supply Module* 200-132-294R
Line Board*
100-242-1199R (100-242-1230R for 4kW
units)
System Controller Board 102-242-1025R
Power Supply Module*
300W / 20 kHz digital 100-244-138R
1.25kW / 20 kHz digital 100-244-102R
2.5kW / 20 kHz digital 100-244-103R
4kW / 20 kHz digital 159-244-075R
750W / 30 kHz digital 100-244-104R
1.5kW / 30 kHz digital 159-244-065R
400W / 40 kHz digital 159-244-064R
800W / 40 kHz digital 159-244-063R
Switch, On / Off; 15A; DPST 200-099-252R
Washer, Mylar
Kit 20 kHz, 10 each (1/2 in. and 3/8 in.) 100-063-357
Kit 20 kHz, 150 each (1/2 in.) 100-063-471
Kit 20 kHz, 150 each (3/8 in.) 100-063-472
Kit 30 kHz, 10 each (3/8 in., 30 kHz) 100-063-632
Fan 100-126-015R
CR2032 Battery for BBRAM 200-262-003
Cover 100-032-454
Cover Screws 200-298-254 (6 ea) 200-298-044 (1 ea)
Line Cord 100-246-1371
Miscellaneous
Other parts such as wrenches, silicon grease, studs, etc., are found in Chapter 5:
Installation and Setup.
*Each of these items must be replaced as a unit.
