108 100-412-234 REV. 06

6.3.4 VGA Monitor

A 15" touchscreen monitor is available from Branson (kit 101-063-855). This touchscreen

monitor can be connected directly to the power supply. Contact your Branson sales

representative for purchasing information (See 1.3 Warranty Statement, Disclaimer).
