6.3.1.2 Point to Point Connection with a Cross-Over Ethernet Cable
If a network does not exist, a shielded Ethernet cable can be used for a point to point
connection between a computer and the 2000Xc Power Supply. The connection can be
made using a crossover Ethernet Cable.
PC Setting
The PC will need to be configured for a static IP Address:
1. From Windows, select: Start > Settings > Network and Dial-Up Connections
2. Select: Local Area Connections > Properties > Internet Protocol > Properties
3. Set the following IP address
IP: 1.1.1.3
Subnet Mask: 255.0.0.0
Gateway: 1.1.1.3
4. Select OK and close all windows.
Welder Setting
The welder also needs to be configured for a static IP Address:
1. Select Windows setup screen from the 2000Xc controller
2. From the Windows screen select: Start > Network Connections
3. Double click Local Area Connection. Click Properties
4. Under Internet Protocol (TCP/IP), set the following IP address manually
IP: 1.1.1.1
Subnet Mask: 255.0.0.0
Gateway: 1.1.1.3
5. Select OK. Close this window by clicking on the “X” on the upper right corner
NOTICE
Most computers now have a cable auto-detect feature that allows
them to establish communication with either a straight through or
cross-over cable.
NOTICE
A mouse and keyboard connected to the USB port is necessary to
navigate through the next several steps.
