Branson 2000Xc - Page 243

230 100-412-234 REV. 06
314
Energy Not
Reached
The weld time has been
extended up to 50% and
the minimum energy has
still not been reached.
Discard the part. If you
encounter numerous or
successive alarms with
good parts, you might
change your minimum
energy setting.
315
Trigger > Weld
Force
The force at the end of
the weld is less than the
trigger force you set.
Increase your downspeed
and/or system pressure.
If you very frequently
receive this alarm,
contact Branson
421 Sonics Disabled
Remove Sonics Disable
input.
2EE Input PIN Conflict
30C No Amplitude Step
The amplitude power step
level was not reached.
Manually inspect the part.
If the part is acceptable,
turn amplitude stepping
off. If the part is not
acceptable, you might
want to adjust your main
parameter.
30D No Amplitude Step
The amplitude step at
external signal input was
not received.
Make sure Ext Signal is
defined in the User I/O.
41B Peak Power Cutoff
The peak power cutoff
was reached. The main
parameter you set for the
weld cycle was not used.
Manually inspect the part.
If the part is acceptable,
you might want to adjust
your main parameter to
avoid this alarm.
41C ABS Cutoff
The absolute distance
cutoff you set was
reached. The main
parameter you set for the
weld cycle was not used
to the end of the cycle.
Manually inspect the part.
If the part is acceptable,
you might want to adjust
your main parameter to
avoid this alarm.
70F
Ground Detect
Abort
The cycle was aborted
because ground detect
occurred during Weld or
Hold
Manually inspect the part.
If the part is acceptable,
you might want to adjust
your main parameter to
avoid this alarm.
Table B.1 Cycle Modified Alarms and Messages, with Probable Cause and Corrective Action
Alarm
ID
Display Message Alarm Condition/Cause Corrective Action
