Branson 2000Xc - Page 245

232 100-412-234 REV. 06
626
Actuator NovRam
Error Code = 10
The Actuator NovRam
has corrupted data
Perform a Cold Start. Check
setup/cable. Repair/replace
Interface board in actuator.
626
Actuator NovRam
Error Code = 20
Cylinder size is not
1.5, 2.0, 2.5, 3.0,
50mm, 63mm, 80mm,
or Custom.
Perform a Cold Start. Check
setup/cable. Repair/replace
Interface board in actuator.
626
Actuator NovRam
Error Code = 30
Stroke length is not 4”,
5”, 6”, 7”, 8”, 80mm,
160mm, or Custom.
Perform a Cold Start. Check
setup/cable. Repair/replace
Interface board in actuator.
626
Actuator NovRam
Error Code = 40
When each successive
element in the
Pressure Sensor
Calibration Table is not
greater than the
preceding one.
Perform a Cold Start. Check
setup/cable.Repair/replace
Interface board in actuator.
626
Actuator NovRam
Error Code = 50
When each successive
element in the Load
Cell Table is not larger
than the preceding
one.
Perform a Cold Start. Check
setup/cable.Repair/replace
Interface board in actuator.
626
Actuator NovRam
Error Code = 60
Could not write to the
actuator NovRam.
Perform a Cold Start. Check
setup/cable. Repair/replace
Interface board in actuator.
627 P/S NovRam
The power supply
NovRam failed. It is
checked only at power
up.
Repair/replace Control Board.
628 Start Sw Time
You did not activate
both start switches
within the required
time interval.
Activate both start switches at
the same time to rerun the
cycle.
629 USB Memory Full
Data was selected to
be saved on the USB
memory stick, but the
memory stick is now
full.
Welding will be stopped until
corrected. If all data from the
weld will not fit, then no data
will be written. All data from
any given weld cycle must be
written on one USB stick.
630
Actuator Clear
Function
The carriage is home
before the actuator
clear condition was
met.
Make sure the linear encoder
cable is connected properly.
Replace Linear Encoder. Repair/
replace Control Board.
Table B.2 Failure of Alarms and Messages, with Probable Cause and Corrective Action
Alarm
ID
Display
Message
Alarm Condition/
Cause
Corrective Action
