Counters
A record of the number of cycles run by category, for example,
alarms, good parts, and so on.
Cycle Aborts Settings that end the cycle immediately.
Digital Filter A smoothing technique used to provide more meaningful data.
Digital Frequency
A specific starting frequency for a horn. Set to Default
(recommended) for factory default starting frequency.
Downspeed
The user-definable speed of descent (percentage of maximum
speed) during the down stroke of the actuator.
Downspeed
Tuning
Run actuator test cycles for measuring speed and allowing fine
adjustments to the speed setting.
Energy Braking
Allows the power supply time to reduce the amplitude before the
sonics are shut off. Any overloads that occur will be ignored in this
state. They will be handled in the hold state.
Energy
Compensation
Extend the weld time up to 50% greater than the weld time setting
or whenever the minimum energy is reached, or shut off the weld
before the expected (set) weld time if the maximum energy value
is reached.
Energy Mode
A mode of operation in which ultrasonics are terminated at a user-
specified energy value.
Event History
A record of changes made to the welder configuration and weld
setup. Records time, date, user ID and comments made for
changes. Used for audit purposes
Executive
Highest authority level allowed to the power supply. The Executive
has access to all configuration and weld setup features. Only the
Executive can create or modify the User ID Setup. Multiple
Executive level users can be created in the User ID table. The User
ID table must contain at least one Executive user.
External
Amplitude Control
Enables you to access real-time amplitude control directly.
External
Frequency Control
Enables you to access real-time frequency control directly.
External U/S
Delay
If External Trigger Delay is enabled, weld state machine shall wait
for external trigger delay input to become active in less than 30
seconds. When the time expires and input is still inactive, alarm
will be recorded and cycle aborted.
Extra Cooling
When On, allows cooling air to start when upper limit switch is
triggered and remains on throughout the cycle. When Off, air is
applied at ultrasonics application.
F Actual
Actual Frequency. The operating frequency of the ultrasonic stack,
as measured during a cycle.
Table 2.3 Glossary of Terms
Name Description
