Horn Down
A mode in which ultrasonics are locked out and the user can
advance the actuator for setup and alignment.
I/O Connector Presets 1 through 32 are available.
Key Reserved for special product configuration codes.
Linear Encoder
Provides carriage (horn) distance measurement during the
actuator cycle.
Main Menu
The list of categories of features available in the software, as
displayed on the front panel of the power supply.
Max Energy
Maximum Energy. The maximum user-specified energy that
produces a part without an alarm. Used with energy compensation
to turn off the weld in Time mode.
Memory Full
Does not allow any welding until memory is cleared. Memory can
be cleared by using Copy Now and deleting memory. If set to
Continue, the system will write over older memory.
Min Energy
Minimum Energy. The minimum user-specified energy that
produces a part without an alarm. Used with energy compensation
to extend the weld to up to 50% of the weld time in Time mode.
Minus Limit
The user-defined lower limit, or lower extreme of an acceptable
range for a given parameter. Used with suspect and reject limits.
Missing Part
A min/max distance where trigger is expected. Returns the
actuator to the home position and displays an alarm indicating that
the cycle was aborted because no part was present.
Operator
Authority level below Technician. The Operator can run a weld and
view system information, weld history, and current setup. The
Operator cannot access the weld setup or configuration menu.
Operator
Authority
Special authority rights granted to operators beyond the basic level
of welder operation. The setting for this is global and applies to all
operator level users. Multiple Operator level users can be created
in the User ID table.
P/Col Graph
Dual Display of% power and collapse distance as a function of
time.
P/Force Graph Dual display of% power and force as a function of time.
Parameter Range Valid range of parameters accepted for a particular setup.
Part-ID Scan
A USB barcode reader or similar device must read and record the
part ID before allowing the weld to occur. When set to ON and after
a weld cycle, the welder will stay out of ready mode until another
part ID is read. If set to OFF, no part ID reading is required before
a weld.
Password
Recovery Kit
PRK. A dongle that plugs into the back of the power supply to
disable authority check.
Table 2.3 Glossary of Terms
