Fig. 166: Bolts At Compounder
Courtesy of CHRYSLER LLC
69. Remove Holder 9908 from the compounder bearing retainer.
70. Install all the bolts at the compounder bearing retainer and tighten to 12 N.m (105 in. lbs.).
Fig. 167: Snap Ring Underdrive Compounder
Courtesy of CHRYSLER LLC
71. Install snap ring (1) at top of the compounder bearing retainer.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
