Cisco ASR 1002 Hardware Installation Guide

◦
Grounding cable lug
◦
Kepnut screw
b) Tighten the Kepnut screws (use the screwdriver to tighten the screw in the terminal block to a torque of 8 in-lbs / 2
per.) on the power supply studs.
Figure 75: Cisco ASR 1004 Router –48 VDC Power Supply Grounding Wire and Stud, on page 214 shows the –48
VDC power supply grounding wire and stud.
Figure 75: Cisco ASR 1004 Router – 48 VDC Power Supply Grounding Wire and Stud
Step 4
Attach the other end of the cable to the site ground connection.
Before you continue to install the terminal block wires, stop and perform Step 5. To prevent any contact with
metal lead on the wire and the plastic cover.
Caution
Step 5
You must wrap the positive and negative cables with sleeving. Take each wire and cover the area from the lug to the
wire with heavy shrink sleeving.
Figure 76: Cisco ASR 1004 Router –48 VDC Power Supply Cable Connection, on page 214 shows the –48 VDC power
supply cable connection.
Figure 76: Cisco ASR 1004 Router – 48 VDC Power Supply Cable Connection
Flat washer4Power supply stud and wire1
Kepnut screw5Ground lug nut2
——
Ground symbol3
Step 6
For easier cable-management, insert the negative cable first. Replace the ground lug with cable in the following order:
a) Flat Washer
b) Ground lug with negative wire
c) Kepnut screw
Step 7
Tighten the Kepnut screw (use the screwdriver to tighten the screw in the terminal block to a torque of 8 in-lbs / 4 per.)
and repeat the same steps for the positive stud and wire.
Secure the wires coming in from the terminal block so that they cannot be disturbed by casual contact.Note
Cisco ASR 1000 Series Router Hardware Installation Guide
214
Cisco ASR 1004 Router Overview and Installation
Connecting --48 VDC Input Power to Cisco ASR 1004 Router

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
