USB port—USB
high-speed (480 Mbps)
port used for secure key
storage, VPN credentials
storage, or bulk flash
storage of image and
configuration backup
This USB port is an A
port.
10
AUX—RS-232 auxiliary
port
4
STAT—Status LED
11
CON—RS-232 console
port
5
PWR—Power LED
12
MGMT—RJ-45
10/100/1000 management
Ethernet port
6
•
IDC-OC3POS
IDC-OC3POS can support two channels of OC3 (see the following image).
Figure 197: Cisco ASR 1001 Router with IDC-OC3POS
LINK LED—Indicates
MGMT Ethernet port
activity
8
C/A—Carrier/Alarm LED
1
BF—Internal bootflash
LED that indicates
activity of the EUSB
device
9
A/L—Active/Loopback
LED
2
