461 • DM NAX® Product Manual — Doc. 9045M
3. Set the Auto Initiation toggle to the right position to enable auto initiation. Set the toggle to the
left position to disable auto initiation.
l
If Auto Initiation is enabled, the stream will begin automatically when the receiver
subscribes to the transmitter.
l
If Auto Initiation is disabled, the stream will not begin until it is manually initiated.
4. To set the port number, do one of the following:
l
Click the arrows to increase or decrease the port number by increments of 1.
l
Manually enter a port number in the Port field. The default port number is 5004.
5. Click OK to save or click Cancel to cancel the changes.
Routing
The Routing section is used to route a local input or AES67 stream to a Zone on the
DM-NAX-AMP-X300.
NOTE: To receive an AES67 stream from Dante devices, see OLH 1001151.
To route an input to a zone, click the box in the routing matrix where the zone's row overlaps the
corresponding input's column. Once a route is made, appears. To break a given route click or .
To route a single input to all zones, click on the icon under the input's name.
Use the arrows ( or ) at the top of the matrix to change pages to view all available inputs.
Port Selection
The Port Selection feature allows the device's internal network traffic to be managed and segregated
based on traffic type. Internal VLANs are used to segment device management and streaming service
traffic to a separate physical device Ethernet port than audio-over-IP streaming traffic. With Port
Selection enabled on all DMNAX devices on a network, DMNAX and AES67 network traffic can be
physically separated from the control network onto a dedicated audio network.
