331 • DM NAX® Product Manual — Doc. 9045M
Network
The Network section contains network-related settings for the DM-NAX-4ZSP, including the Hostname,
Domain, Primary Static DNS, and Secondary Static DNS.
NOTE: By default, the hostname of the DM-NAX-4ZSP consists of the model name followed by the
MAC address of the device. For example, DM-NAX-4ZSP-00107FB58088.
Adapter 1
The Adapter 1 subheading contains settings for DHCP, IP Address, Subnet Mask, and Default Gateway
of Ethernet adapter 1 on the rear panel of the device.
NOTES:
l
An + Adapter 2 option only appears when the dual Ethernet ports on the DM-NAX-4ZSP are
set to isolate traffic using the Port Selection feature. The settings for Adapter 2 are identical
to those available for Adapter 1.
l
DMNAX devices' internal processes use IP addresses in the 10.10.10.
xxx
range. This IP range
should be avoided when addressing DMNAX devices to prevent conflicts.
Set the DHCP toggle to enabled (right) or disabled (left) to specify whether the IP address of the DM-
NAX-4ZSP is to be assigned by a DHCP (Dynamic Host Configuration Protocol) server.
l
Enabled: When DHCP is enabled (default setting), the IP address of the DM-NAX-4ZSP is
automatically assigned by a DHCP server on the local area network (LAN).
l
Disabled:When DHCP is disabled, manually enter information in the following fields:
o
Primary Static DNS: Enter a primary DNS IP address.
o
Secondary Static DNS: Enter a secondary DNSIPaddress.
o
IP Address: Enter a unique IP address for the DM-NAX-4ZSP.
o
Subnet Mask: Enter the subnet mask that is set on the network.
o
Default Gateway: Enter the IP address that is to be used as the network’s gateway.
