185 • DM NAX® Product Manual — Doc. 9045M
Create Local Group
1. Click the Create Group button.
2. In the Create Group dialog, enter the following:
a. Enter the group name in the Name field.
b. Assign the group access level by selecting a predefined access level (Administrator,
Connect, Operator, Programmer, User) from the Access Level drop-down list.
NOTE: Make sure that the Active Directory Group toggle is disabled.
3. Click OK to save. Click Cancel to cancel the changes.
Add Active Directory Group
A group cannot be created or removed from the Active Directory server, but access can be granted to an
existing group in Active Directory.
Once the group is added, all members of that group will have access to the DM-NAX-2XLRI-1G.
1. Click the Create Group button.
2. In the Create Group dialog enter the following:
a. Enter the group name in the Name field, for example “Engineering Group”. Note that group
names are case sensitive; a space is a valid character that can be used in group names.
