Crestron DM NAX Series - DM-NAX-BTIO-1 G Installation; In the Box; Mount the Device; Mounting under a Table

132 • DM NAX® Product Manual — Doc. 9045M
DM-NAX-BTIO-1G Installation
Refer to the following sections to install the DM-NAX-BTIO-1G.
l
In the Box on page 132
l
Mount the Device on page 132
l
Connect the Device on page 134
l
Reset the Device on page 135
In the Box
Qty. Description
1 DM-NAX-BTIO-1G
Additional Items
1 Metal mounting bracket, steel (2016054)
2 Screw, 06-32, 1/4in., Pan Head, Phillips (2007218)
2 Screws, 6-32 x 3/4in., Truss Head, Combo (2009211)
Mount the Device
The DM-NAX-BTIO-1G can be mounted under a table or into a 1-gang electrical box.
Mounting under a Table
To mount the device under a table:
