Product Manual — Doc. 9045M DM NAX® • 65
DM-NAX-2XLRI-1G Installation
Refer to the following sections to install the DM-NAX-2XLRI-1G.
l
In the Box on page 65
l
Mounting the Device on page 65
l
Connect the Device on page 68
l
Reset the Device on page 69
In the Box
Qty. Description
1 DM-NAX-2XLRI
Additional Items
2 Screw, 06-32, 3/4 in., Truss Head, Combo (2009211)
Mounting the Device
The DM-NAX-2XLRI-1G can be mounted into a 1-gang electrical box or onto a rack rail.
Mounting into a 1-Gang Electrical Box
NOTES:
l
The DM-NAX-2XLRI-1G should only be mounted with a RACO® 3in. x 2in. x 2in. gangable
metal switch box with eight 0.5in. knockouts and plaster ears (catalog ID #420), as it was
designed to fit the box dimensions and knockout placements. Alternative metal switch boxes
should not be used as they may have different knockout placements, which can lead to issues
running the PoE connection to the unit due to cable bend radius restrictions.
l
For thermal performance reasons, fully enclosed plastic back boxes should not be used with
the DM-NAX-2XLRI-1G. In installations where an enclosed back box is not required, the
DM-NAX-2XLRI-1G can be installed into most single gang metal or plastic mud rings.
l
Connector boots should not be used on CAT5e (or greater) cables being connected to the
DM-NAX-2XLRI-1G to avoid cable bend radius issues.
To mount the wall plate into a 1-gang electrical box, follow the instructions below.
