7. Other Field Service Ver. 1.0 Aug. 2005
72
bizhub 200/250/350
Maintenance
7. Remove four screws [5] and two har-
ness protective metal brackets [6].
8. Remove the harness from the cord
holder.
9. Remove five screws [7] and the
Mechanical Control Board Cover [8].
10. Remove two flat cables (PJ3, PJ35)
[9].
11. Remove three screws [10] and the
PH Unit [11].
4040F2C613DA
[5]
[6]
[5]
[6]
[5]
4040F2C614DA
4040F2C615DA
[8]
[7]
4040F2C674DA
[9]
4040F2C616DA
[11]
[10]
[10]
