Field Service Ver. 1.0 Aug. 2005 11. Tech. Rep. Mode
171
bizhub 200/250/350Adjustment / Setting
SW2
Toner/Side Cover
Side Cover Right Side Door Interlock Switch 1
Out of
position
Set
PC5 Front Cover Front Door Sensor
Out of
position
Set
SW4
Sub Hopper
Empty
Sub Hopper Empty Switch
Toner not loaded: 1 and
0 alternately displayed.
Toner loaded: 0 dis-
played
M1
Drive Motor Detect
Main Motor Main Motor
When
turning
When
stopped
M2 I/U Motor IU Motor
When
turning
When
stopped
M9 Polygon Motor Polygon Motor
When
turning
When
stopped
M4
Cooling Fan
(Power Supply)
Power Supply Cooling Fan Motor
When
turning
When
stopped
M5 Cooling Fan Cooling Fan Motor
When
turning
When
stopped
M6 IU Cooling Fan IU Cooling Fan Motor
When
turning
When
stopped
M11
Toner Suction Fan
(Ventilation)
Toner Suction Fan Motor
When
turning
When
stopped
Symbol Panel Display Part/Signal Name
Operation Characteris-
tics/ Panel Display
10
