Field Service Ver. 1.0 Aug. 2005 11. Tech. Rep. Mode
173
bizhub 200/250/350Adjustment / Setting
B. Scanner
C. Job Tray
D. Sheet-through-ADF (2-sided)
Symbol Panel Display Part/Signal Name
Operation Characteris-
tics/ Panel Display
10
PC208
Scanner
Scanner (HP) Scanner Home Sensor At home
Out of
home
SW201 Size reset S Size Reset Switch Lowered Raised
PC209
Orig. cover
detecting S
Original Cover Angle Sensor
Less than
15°
15° or
more
Symbol Panel Display Part/Signal Name
Operation Characteris-
tics/ Panel Display
10
PC1-JOB
Job Tray
Upper Tray Full Paper Full Detection Sensor Blocked Unblocked
 Turn Over Unit Switch Back Unit Set signal Set Not set
 Job Tray Job Tray Set signal Set Not set
Symbol Panel Display Part/Signal Name
Operation Characteris-
tics/ Panel Display
10
PC5-ADF
Sheet-through-ADF (2-sided)
Empty Empty Sensor
Paper
present
Paper not
present
PC9-ADF Registration Registration Sensor
Paper
present
Paper not
present
PC8-ADF Before Scanning Original Detection Sensor
Paper
present
Paper not
present
PC10-ADF Exit and Turn Over Exit/Turnover Sensor
Paper
present
Paper not
present
PC1-ADF Orig. Length 1 FD Paper Size Detection Sensor 1
Paper
present
Paper not
present
PC2-ADF Orig. Length 2 FD Paper Size Detection Sensor 2 Blocked Unblocked
PC3-ADF Orig. Length 3 FD Paper Size Detection Sensor 3
Paper
present
Paper not
present
PC4-ADF Orig. Length 4 FD Paper Size Detection Sensor 4
Paper
present
Paper not
present
PC6-ADF Behind Separator Separator Sensor Blocked Unblocked
PWB-SIZE
Org. Width Detect
0
Mix Document Size Detection Board
Paper
present
Paper not
present
Org. Width Detect
1
Paper
present
Paper not
present
Org. Width Detect
2
Paper
present
Paper not
present
PC7-ADF Side Cover Upper Door Open/Close Sensor Open Close
PBA-VR Orig. Width Vol. Variable Resistor Analog value
