Develop ineo 350 - Page 449

11. Soft Switch List Field Service Ver. 1.0 Aug. 2005
80
FK-503
Adjustment / Setting
MODE Factory setting bit
047
Bit: 7654 3210
1000 1000
HEX:88
Bit Feature
Logic
Description
01
7 Select V. 34 fall back toler-
ance. (TX)
Bit 7-5: 000 0
60011
50102
011 3
100 4
Others Not available
4 Select V. 34 fall back toler-
ance. (RX)
Bit 4-2: 000 0
30011
2
010 2
011 3
100 4
Others Not available
MODE Factory setting bit
048
Bit: 7654 3210
1100 0110
HEX:C6
Bit Feature
Logic
Description
01
7 Select V.34/V.33/V.17
capabilities.
Bit 7-6: 00 No capability
above 9600 bps
Sets MODEM’s
function
6
01 V.33
10 V.17 & V.33
11 V.17 & V.33 & V.34
2 Allow V.34. No
Yes Should be same as “V.8 (MODE 48 Bit
1)”
1 Allow V. 8. No
Yes Should be same as “V.8 (MODE 48 Bit
2)”
0 Allow V.34 communication
for extensions.
V.3 4 V. 1 7
