Field Service Ver. 1.0 Aug. 2005 11. Soft Switch List
81
FK-503Adjustment / Setting
MODE Factory setting bit
049
Bit: 7654 3210
0000 1101
HEX:0D
Bit Feature
Logic
Description
01
4 Select upper limit of trans-
mission speed. (TX)
Bit 4-0: 00000 2400 bps • Need to disable “V.34
capability (MODE 048
Bit 2)” by setting “No”
for 2400 bps.
• 16.8 kbps or faster are
valid only when “Allow
V.34. (MODE 048 Bit
2)” is enabled (Yes).
3 00001 4800 bps
2 00010 7200 bps
1 00011 9600 bps
0 00100 12.0 kbps
00101 14.4 kbps
00110 16.8 kbps
00111 19.2 kbps
01000 21.6 kbps
01001 24.0 kbps
01010 26.4 kbps
01011 28.8 kbps
01100 31.2 kbps
01101 33.6 kbps
Others Not available
MODE Factory setting bit
050
Bit: 7654 3210
0000 1101
HEX:0D
Bit Feature
Logic
Description
01
4 Select upper limit of trans-
mission speed. (RX)
Bit 4-0: 00000 2400 bps • Need to disable “V.34
capability (MODE 048
Bit 2)” by setting “No”
for 2400 bps.
• 16.8 kbps or faster is
valid only when “Allow
V.34 (MODE 048 Bit
2)” is enabled (Yes).
3 00001 4800 bps
2 00010 7200 bps
1 00011 9600 bps
0 00100 12.0 kbps
00101 14.4 kbps
00110 16.8 kbps
00111 19.2 kbps
01000 21.6 kbps
01001 24.0 kbps
01010 26.4 kbps
01011 28.8 kbps
01100 31.2 kbps
01101 33.6 kbps
Others Not available
