11. Soft Switch List Field Service Ver. 1.0 Aug. 2005
86
FK-503
Adjustment / Setting
NOTE
• The upper limit (Bit 5 to 3) must be higher than the lower limit (Bit 2 to 0).
MODE Factory setting bit
083 (PSTN1)
Bit: 7654 3210
0101 0000
HEX:50
Bit Feature
Logic
Description
01
7 Monitoring cycle of hook-
ing
Bit 7-6: 00 12 msec
6
01 24 msec
10 36 msec
11 48 msec
5 Select upper limit of
detecting as hooking
(Adjustment of voltage
detected as hooking)
Bit 5-3: 000 8 V
4 001 11 V
3
010 14 V
011 19 V
100 25 V
101 31 V
110 36 V
111 42 V
2 Select lower limit of
detecting as hooking
(Adjustment of voltage
detected as hooking)
Bit 2-0:
000 3 V
10015 V
00108 V
011 11 V
100 14 V
101 17 V
110 19 V
111 22 V
