Field Service Ver. 1.0 Aug. 2005 11. Soft Switch List
87
FK-503Adjustment / Setting
MODE Factory setting bit
084 (PSTN1)
Bit: 7654 3210
0001 1100
HEX:14 (For U.S.)
HEX:28 (For Europe)
114 (PSTN2)
HEX:14 (For U.S.)
HEX:1C (For Europe)
Bit Feature
Logic
Description
01
5 Select PB sending level. Bit 5-2: 0000 -1 dBm
4 0001 -2 dBm
3 0010 -3 dBm
2 0011 -4 dBm
0100 -5 dBm
0101 -6 dBm
0110 -7 dBm
0111 -8 dBm
1000 -9 dBm
1001 -10 dBm
1010 -11 dBm
1011 -12 dBm
1100 -13 dBm
1101 -14 dBm
1110 -15 dBm
1111 -16 dBm
MODE Factory setting bit
085 (PSTN1)
Bit: 7654 3210
1001 0000
HEX:90 (For U.S.)
HEX:C0 (For Europe)
115 (PSTN2)
HEX:90 (For U.S.)
HEX:90 (For Europe)
Bit Feature
Logic
Description
01
7 Select TX level. Bit 7-4: 1000 -9 dBm Specifies TX levels other
than PB.
6
1001 -10 dBm
5 1010 -11 dBm
4 1011 -12 dBm
1100 -13 dBm
1101 -14 dBm
1110 -15 dBm
1110 -16 dBm
Others Not available
