Field Service Ver. 1.0 Aug. 2005 11. Soft Switch List
99
FK-503Adjustment / Setting
NOTE
• The features with (*) are settable by users. *: Screen setting
NOTE
• The features with (*) are settable by users. *: Screen setting <*>: Soft switch setting
MODE Factory setting bit
288
Bit: 7654 3210
1111 1111
HEX:FF
Bit Feature
Logic
Description
01
7 Insert dummy data before
PIX.
Bit 7-0: 00H Add 200 ms • Changes not allowed.
• Specify period to
transmit dummy data
before transmitting
PIX.
• Add the period speci-
fied here to the first
flag (EMC) and FILL
(G3) of the image sig-
nal.
6
5 01H Add 300 ms
(200 ms +
100 ms)
4
3
2
1 07H Add 900 ms
(200 ms +700
ms)
0
FFH Add 200 ms
Others Not available
MODE Factory setting bit
310
Bit: 7654 3210
0000 0000
HEX:00
Bit Feature
Logic
Description
01
7 Increase of sound level *
Normal
sound
level
mode
Increased
sound
level
mode
MODE Factory setting bit
311
Bit: 7654 3210
0000 0000
HEX:00
Bit Feature
Logic
Description
01
7 Invert screen *
Normal Inverted
6 Displaying next screen
when using Enlarge Dis-
play <*>
Wait for
specifi-
cation
Display
upper-left
screen
