B • Installation
Doc. 065051-03 1/08 209
Select the Sample Mode
1. On the MODULE SETUP MENU, press 5 to go to the SYSTEM
PARAMETERS
screen (see Figure B-43).
2. Move the cursor to the
SAMPLE MODE field and select the mode (see
Table B-1)
. Refer to Section 3-16 for details about the AS sample
modes.
Figure B-43. System Parameters Screen Example: Normal Mode Selected
SAMPLE MODE DESCRIPTION
NORMAL (default)
Injections to a single system
CONCENTRATE
Injections to a single system when the sample loop
is replaced by a concentrator column
SIMULTANEOUS
Injections to two systems simultaneously
SEQUENTIAL
Injections to two systems in sequence
SEQUENTIAL
CONCENTRATE
Injections to two systems in sequence when the
sample loop is replaced by a concentrator column
Table B-1. AS Sample Modes
Help Prompt
SYSTEM PARAMETERS
WAIT:
ENABLED
METHOD SYRINGE SPEED:
CUT SEGMENT VOLUME:
INJECT PORT VOLUME:
uL
uL
10
S1 43
3
SAMPLE MODE:
NORMAL
FLUSH SYRINGE SPEED:
4
uLS2
