296 Hog 4 Operations Manual
16.3.2 Lowlight
By default, the parameters of fixtures that are not selected when you use highlight remain at
their current output values. You can customise the output values of these parameters during
highlight by creating a lowlight palette. For example, you could create a lowlight palette that
sets the intensity of all fixtures to 30%, to give the highlighted fixture greater contrast.
Note that lowlight only affects parameter values of the non-selected fixtures in the current
editor. Parameter values being output by playbacks will not be affected.
To assign a pre-existing palette to be the lowlight palette, right-click it in the palette directory
and select it as the lowlight palette. The lowlight palette is shown by the icon in the
palette directory window.
Tip: You can use masking when creating the lowlight palette to ensure that all the required
parameter types are included; see Recording Palettes with Kind Masking.
