310 Hog 4 Operations Manual
Commands assignable to all keys:
"Scale Playback Rate" then a button assigned to "Scale Fader Assignment" will
scale the playback rate).
•
Temporary:When temporary is turned on scaling will be applied when button is
pressed down and released when when button is released.
•
Action and Value: When action = "multiply" then button press will multiply
scaling value by the value specified; when action = "set" then button press will
change rate scaling value to value specified.
Commands Assignable to Fader Control
Command Options and Notes
None Disables the control
I Fader
The fader controls fixture intensities being output by the master.
•
Go Off Zero:The cuelist is triggered when the fader is moved from zero, as if you
had pressed the Go key.
•
Release At Zero:The cuelist is released when the fader returns to zero; see
Releasing Masters.
Manual
crossfader
The fader controls the crossfading between cues manually: move the fader to the
bottom to ‘pick up’ the next cue, then move it up to start the crossfade.
IPCB
crossfader
The fader manually controls the crossfading of the intensity, position, colour, and
beam parameters of the current cue. When the fader is at the top of its travel the
current cue will be 100% crossfaded onto stage. When the fader is at the bottom of its
travel the current cue will be completely released.
Scale
Playback
Rate
The fader adjusts the playback rate of the master by applying a scaling value to the
base playback rate of the master.
•
Upper Bound: :Determines the amount of scaling applied to the master when the
fader is at top of travel (Full).
•
Lower Bound:Determines the amount of scaling applied to the master when the
fader is at bottom of travel (0).
Scale
Effect Rate
The fader adjusts the effect rate of the master by applying a scaling value to the base
effect rate of the master.
•
Upper Bound:Determines the amount of scaling applied to the master when the
fader is at top of travel (Full).
•
Lower Bound:Determines the amount of scaling applied to the master when the
fader is at bottom of travel (0).
Scale
Effect Size
The fader adjusts the effect size of the by applying a scaling value to the base effect
size of the master.
•
Upper Bound:Determines the amount of scaling applied to the master when the
fader is at top of travel (Full).
•
Lower Bound:Determines the amount of scaling applied to the master when the
fader is at bottom of travel (0).
