56 Hog 4 Operations Manual
To connect an external display and / or touchscreen to your console:
1. Power off the console.
2. Connect the external display's video signal cable to one of the video output
connections on the back of the console. A video adapter may be required (see tip
below).
3. If using a touchscreen: connect a USB cable from the touchscreen to one of the USB
ports on the console.
4. Turn on the console.
5. In most cases each external monitor's native resolution will be detected by the console
and no further adjustments to resolution will be required. In cases where the external
monitor's resolution is not properly set automatically, press the control panel button on
the start screen to open the control panel.
6. Select the "displays" tab of the control panel. Use the appropriate drop down menus to
select a custom or preset monitor resolution, orientation, and/or position for the external
display and then press the apply button.
7. If using a touchscreen: press the first encoder wheel button while holding down the
setup key on the front panel. This will start the touchscreen calibration utility.
8. Touch all of the calibration targets on both the internal and external touchscreen
displays. Once calibration is complete the cursor should follow your finger on both the
internal and external touchscreen displays.
Tip:
Hog 4-18
The display port output connections can be used directly with DP
displays or ACTIVE DP video adapters to other connector types.
Hog 4-18
The display port outputs are NOT compatible with PASSIVE video
adapters.
Full Boar 4
The DVI-D output connections do not support analog output to
VGA displays.
Road Hog 4
VGA output is not supported. It is advised to only use the DVI-D
output on the back of the Road Hog 4.
Caution: Some Elo Touchscreens do not follow the USB specification for back voltage
(USB 2.0 Specification, Section 7.1.2 and 7.1.5) and may posed a risk to the BIOS on the
following Hog consoles:
Road Hog 4-21
Full Boar 4
HedgeHog 4X (2021)
For this reason Elo touch monitors are not recommended for use on these consoles.
