4.5 Setting Application Settings
125
4
Chapter 4 LCR Function
Range synchronization function settings (Rdc)
Procedure
LCR Measurement Screen Rdc Basic Settings
1
When the range synchronization function is enabled (p. 120)
Press .
2
Rdc Basic Settings (Range Synchronization Function)
3
Select the measurement range you wish to
configure with and and configure the
associated functions.
LCR Range Synchronization Function
Settings Screen (Rdc)
Sets the measurement speed (p. 98).
Configures averaging (p. 99).
Settings are the same as those described in "4.3 Setting DC
Resistance Measurement" (p. 80).
Allows you to configure functions on a single screen (p. 127).
Cancels the setting and returns to the previ-
ous screen.
4
Press to close the setting screen.
