9. Disconnect the OMAS Cable from the OMAS Controller Card.
10. Unroute the OMAS Cable from the Ferrite Core.
11. 10.Unroute and remove the OMAS Cable from the printer.
Installation
CAUTION: It is critical that the OMAS Cable is correctly positioned in the Vacuum Beam so that it does not
cause physical interference to the Media Sensor.
The following illustration shows a cross-section of the Vacuum Beam with the OMAS Cable correctly routed to
avoid interference to the Media Sensor.
ENWW Disassembly order 353
