Chapter 5 List of Parameters 5.1 I/O Parameters
173
I/O Parameters
No. Parameter name
Default
value
(Reference)
Input range Unit Remarks
373 (For extention) Common 0
374 (For extention) Common 0
375 (For extention) Common 0
376 (For extention) Common 0
378 (For extention) Common 0
379 (For extention) Common 0
380
Invalid General Use
Output Area 2 Number
Min. at All Axes Program
Finish
Common 0 0 ~ 599
* Caution: The output from this area should be taken place under
the responsibility of the user program including “I/O Process
Program at Operation Program Finish”. All the outputs except
for those from this area should be compulsorily shut off.
(Invalid when 0)
(It is applicable for main application part V1.17 and later of the
pulse motor type and from the first lot of the AC servomotor type)
381
Invalid General Use
Output Area 2 Number
Max. at All Axes Program
Finish
Common 0 0 ~ 599
(It is applicable for main application part V1.17 and later of the
pulse motor type and from the first lot of the AC servomotor type
382 (For extention) Common 0
383 (For extention) Common 0
384 (For extention) Common 0
385 (For extention) Common 0
386 (For extention) Common 0
387 (For extention) Common 0
388 (For extention) Common 0
389 (For extention) Common 0
390
Invalid General Use
Output Area 2 Number
Min. at All Operation
Paused (Servo Axis
Software Interlock +
Output Port Software
Interlock)
Common 0 0 ~ 599
* Caution: The output from this area should be taken place under
the responsibility of the user program including “I/O Process
Program at All Operation Paused” (including recovery). All the
outputs except for those from this area should be compulsorily
shut off and paused (only when in automatic operation) with
reflecting the result from the operation during the pause of all
the operations. (Invalid when 0)
(It is applicable for main application part V1.17 and later of the
pulse motor type and from the first lot of the AC servomotor type)
391
Invalid General Use
Output Area 2 Number
Max. at All Operation
Paused (Servo Axis
Software Interlock +
Output Port Software
Interlock)
Common 0 0 ~ 599
(It is applicable for main application part V1.17 and later of the
pulse motor type and from the first lot of the AC servomotor type)
392 (For extention) Common 0
393 (For extention) Common 0
394 (For extention) Common 0
395 (For extention) Common 0
396 (For extention) Common 0
397 (For extention) Common 0
398 (For extention) Common 0
399 (For extention) Common 0
400 (For extention) Common 0
401
to
601
(For extention) Common 0
602
IA Net occupation station
top number
Common 0 0 ~ 63
603
IA Net resizing execution
station number
Common 0 0 ~ 63
The station number to optimize the communication cycle time at
IA Net startup
* Set up the same value in all the controllers in the same network.
It is necessary that the resizing execution station is only one in
one network.
* Indicate the top station number that the controller occupies.
604
IA Net last station
number
Common 63 0 ~ 63
The last station number in one network
* Set up the same value in all the controllers in the same network.
It is necessary that the resizing execution station is only one in
one network.
605
IA Net all connection
station pattern (31-00)
Common 0H
0H ~
FFFFFFFFH
Make the connection status of Station No. 31 to No. 0 as the bit
patterns with 0: Connected, 1: Connected, and input by
converting to hexadecimal numbers.
606
IA Net all connection
station pattern (63-32)
Common 0H
0H ~
FFFFFFFFH
Make the connection status of Station No. 63 to No. 32 as the bit
patterns with 0: Connected, 1: Connected, and input by
converting to hexadecimal numbers.
To Next Page
