Chapter 5 List of Parameters5.3 Axis-Specic Parameters
182
Axis-Specific Parameters
No. Parameter name
Default
value
(Reference)
Input range Unit Remarks
Pulse
Motor
Type
2500
-99999999 ~
99999999
0.001mm
Offset travel distance from the ideal phase-Z position (Positive
value = Applied in the direction of moving away from the end)
21
Offset travel distance at
home return
AC Servo
Motor
Type
1000
-99999999 ~
99999999
0.001mm
Offset travel distance from the ideal phase-Z position (Positive
value = Applied in the direction of moving away from the end)
* Caution for Absolute Encoder
If an integer multiplied vicinity number to the distance between
Z-phases is set to this parameter, there could be a concern that
the coordinate slide for a pitch of a pulse between Z-phases as
the servo lock may occur on the Z-phase at the absolute reset.
Make sure that you will never establish the setting to an integer
multiplied vicinity number to the distance between Z-phases.
Ensure enough margin to the servo system vibration width.）
22
Allowable value for
phase Z position error
check during home
return
Common 0
0 ~
99999999
0.001mm
Allowable actual minimum distance between the end (Mechanical
or LS) and phase Z when a rotary encoder is used.
23 System reservation Common 1 1 ~ 8
24
Push stop check time at
home return
Common 1500 1 ~ 5000 msec Used to confirm pusing action at the time of home return.
25
Push stop check time at
positioning
Common 500 1 ~ 5000 msec Used to confirm pusing action according to the PUSH command.
26 System reservation Common 1000 0 ~ 99999 0.001mm
Pulse
Motor
Type
5000 1 ~ 99999
rpm.mm/
sec
Rpm value in the case of a rotary encoder (Change prohibited)
27
System reservation
(Change prohibited)
AC Servo
Motor
Type
10000 1 ~ 99999
rpm.mm/
sec
28
Maximum operating
speed of each axis
Common 800 1 ~ 9999 mm/s
29 VLMX speed Common 800 1 ~ 9999 mm/s
During VLMX operation, the maximum operating speed of each
axis or VLMX speed, whichever is lower, is used as the maximum
speed of the applicable axis.
30 Servo ON check time Common 20 0 ~ 5000 msec
Brake equipped: Time after receiving a servo-ON start
response until start of brake unlocking
Brake not equipped: Time after receiving a servo ON start
response until transition to an
operation-enabled status
31
Offset travel speed at
home return
Common 3 1 ~ 500 mm/sec
32
Actual distance between
phase Z and end
Common 0 -1 ~99999 0.001mm
Absolute distance from the end (Mechanical or LS). Obtained
automatically if the distance is a negative value. When multiple
actuators are combined, it is recommended to write the flash
ROM after automatic acquisition.
33
Ideal distance between
phase Z and end
Common 0 0 ~ 99999 0.001mm Absolute distance from the end (Mechanical or LS).
34
Brake equipment
specification
Common 0 0 ~ 1
0: Not equipped
1: Equipped
35 Brake unlock check time Common 10 0 ~ 3000 msec
Time after receiving a brake-unlock start response until transition
to an operation-enabled status
36 Brake lock check time Common 10 0 ~ 1000 msec
Time after receiving a brake-lock start response until start of
servo OFF
37 System reservation Common 0 0 ~ 1
Pulse
Motor
Type
2 0 ~ 2 2: Battery-less Absolute
38 Encoder ABS/INC type
AC Servo
Motor
Type
1 0 ~ 2
1: Battery-less Absolute
39 System reservation Common 1 0 ~ 1
40 System reservation Common 0 0 ~ 1
41 System reservation Common 25 0 ~ 100 DRVVR
42 Encoder resolution Common 800
0 ~
99999999
Pulse/rev
, 0.001
μm/pulse
Pulses (before division)/rev, in the case of a rotary encoder
43 Encoder division ratio Common 0 -7 ~ 7 Pulses are multiplied by (“n” th power of 1/2).
44
Length measurement
correction
Common 0
-99999999
~
9999999
9
0.001mm
/1M
Valid only for linear movement axes.
(Coordinates other than the encoder reference Z point will change
proportionally.)
45 (For extension) Common 0
46 (For extension) Common 0
To Next Page
