Chapter 8 Maintenance and Inspection8.6 Replacement of Timing Belt
282
Procedures to Replace Belt on X, Y and Z Axes
In this section, explains how to replace the belt on each axis.
In this instruction, explanation is conducted using A Type 3-Axis Pluse Motor 200 Stroke Type (Model
Code: TTA-A3-20-20).
<Required Tools/Measurement Equipment>
● Hexagon Wrench ● Phillips screwdriver ● Sonic Belt Tension Meter (Model Code: U-508)
● Spring Scale (Tension 58N or more) ● Cable Bands
*: The procedures to replace the belt are in common for all the sizes.
*: For C Type, the structure of the X-axis differs from A Type. Refer to procedures to replace the belt
on the Y-axis of A Type for how to replace the belt on X-axis of C Type.
*: Refer to the separate document “Procedures to Replace Belt on ZR-Axis in TTA” for the ZR-axis.
Z-axis
Y-axis
X-axis
To Next Page
