Chapter 8 Maintenance and Inspection8.6 Replacement of Timing Belt
294
[Z-axis Step (11)]
Check the belt tension.
Tension to Pass: Refer to documents
described in Pg. 279
to 280
[Measurement equipment:
Sonic belt tension meter]
[Z-axis Step (12)]
Assemble back each component in the back order of the procedures.
Pay attention not to pinch the cables when installing Motor Cover Z and BOX Cover.
[Tools: Hexagon wrench, Phillips screwdriver]
To Next Page
