10-24 FUEL SYSTEM / FUEL TANK (MY18+)
ICON A5 / MAINTENANCE MANUAL CHANGE C2
17. Connect T9028 ring terminal from fuselage wire harness to bolt and washer on fuel level sensor.
a. Use a 7/16 wrench to remove bolt and washer. (See Figure 10-7.)
b. Apply LOCTITE 243 to bolt threads and install T9028 ring terminal beneath the washer.
c. Torque bolt to 40-45 in-lb.
18. Secure T9028 ring terminal wire harness and fuel level sensor wire harness to fuel tank with
three CABLE-TIE, NYLON 6-6, 30LB.
19. Fill the tank with fuel and check for leaks.
20. Run the engine and check for line leaks.
21. Install the seat backs. (See “Seat Back Installation” on page 3-51.)
22. Install the baggage sidewall panels. (See “Baggage Sidewall Panel Installation” on page 3-45.)
23. Install baggage floor. (See “Baggage Floor Installation” on page 3-42.)
24. Install headliner. (See “Headliner Installation” on page 3-38.)
VERIFICATION METHOD:
The procedure is complete when the fuel tank is installed with no leak.
RELATED INFORMATION:
"Headliner Installation" on page 3-38
"Baggage Floor Installation" on page 3-42
"Baggage Sidewall Panel Installation" on page 3-45
"Seat Back Installation" on page 3-51
