16-96 PROPULSION / PROPELLER
ICON A5 / MAINTENANCE MANUAL CHANGE C2
NAS1149C0316R (WASHER, FLAT, CRES, .188X.016, PSVT)
NAS1149C0332R (WASHER, FLAT, CRES, .203X.032, PSVT)
NAS1149C0363R (WASHER, FLAT, CRES, .188X.063, PSVT)
NASM970C3 (WASHER, FENDER, CRES, .203X.875X.063)
98370A027 (WASHER, FLAT, 18-8SS, .203X.500X.080-.099)
Aircraft System and Number
13—Propulsion
Consumables
ICA012078 (LUBRICANT, GENERAL PURPOSE) Tef-Gel
®
SpeedTape (or equivalent aluminum pressure-sensitive tape)
3M 7610 (TAPE, REFLECTIVE, 3M SCOTCHLITE)
1. Ensure spinner dome has been installed. (See “Install Spinner Dome” on page 16-106.)
2. Remove the top engine cowl only. (See “Remove Engine Cowlings” on page 16-13.)
3. Install accelerometer (vibration sensor) onto the gearbox per Propeller Balance System manual.
Ensure sensor is secured tightly and oriented vertically. See Figure 16-59 as an installation
example.
