17-26 WING / WING LOCK
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 17
RELATED INFORMATION:
"Wing Lock Handle Removal" on page 17-28
"Wing Lock Mounting Plate Component Replacement" on page 17-33
17.5.1.2 Wing Lock Switch Mounting Plate Installation
Use the following procedure to install the wing lock switch mounting plate.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
ICA008395 (PIN, WING LOCK SWITCH)
ICA008397 (PIN, ACTUATION, WING LOCK SWITCH)
ICA008701 (CATCH, WING LOCK HANDLE)
ICA009633 (SWITCH, LIMIT, WING LOCK LEVER, LH)
ICA009635 (SWITCH, LIMIT, WING LOCK PAWL, LH)
ICA010840 (EXTENDED LATCH PAWL, WING LOCK SWITCH)
ICA013017 (MOUNTING PLATE, WING LOCK SWITCH)
ICA013018 (LATCH MOUNT, WING LOCK SWITCH)
ICA013020 (SENSOR MOUNT, WING LOCK SWITCH, LH)
6C37MTT3 (SCREW, MACH TRH, 6LOBE, CRES, 6-32X.375)
92949A118 (SCREW, BUTTON SHCS, SS, 4-40X1.250)
9435K520 (SPRING, COMPRESSION, CRES, .300X.875X2.61LB/IN)
95630A234 (WASHER, FLAT, PTFE, #4X.030)
98019A309 (WASHER, FLAT, SS, #4X.250X.020-.030)
98408A116 (RETAINING RING, SIDE-MOUNT EXT, CRES, .125X.020)
98408A120 (RETAINING RING, SIDE-MOUNT EXT, CRES, .250X.029)
MS21043-04 (NUT, SLFLKG, RDC HEX, CRES, 4-40)
MS21043-06 (NUT, SLFLKG, RDC HEX, CRES, 6-32)
Aircraft System and Number
14—Wing
