17-28 WING / WING LOCK
ICON A5 / MAINTENANCE MANUAL CHANGE C2
3. Further inspect the wing lock switch mounting plate assembly and replace any unserviceable
parts. Be certain that the structure of the plate is not bent of damaged.
4. Connect the two micro switch connectors to the aircraft electrical harness.
a. LH lock mechanism: D9021P connects to D9021I. D9022P connects to D9022I.
b. RH lock mechanism: D9065P connects to D9065I. D9066P connects to D9066I.
5. Align the mounting holes and install the mounting plate assembly on the fuselage BL38 Rib with
three 8-32 8C50MTT3 truss-head screws, torquing them each to 13 in-lb
f
with a T15 Torx driver.
6. Install the wing fold lock handle. (See “Wing Lock Handle Installation” on page 17-30.)
RELATED INFORMATION:
"Wing Lock Handle Installation" on page 17-30
"Wing Lock Mounting Plate Component Replacement" on page 17-33
17.5.1.3 Wing Lock Handle Removal
Use the following procedure to remove the wing lock handle.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
14—Wing
Consumables
None
1. Fold wing. (See “Wing Fold Procedure” on page 18-3.)
2. Unlatch the wing from the horizontal tail and pull it fully aft. Support it in this position by hanging
the wing tip with straps from an engine hoist or other suitable arrangement.
