17-36 WING / WING LOCK
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 17
9. Install the wing lock switch mounting plate. (See “Wing Lock Switch Mounting Plate Installation”
on page 17-26.)
10. Install the wing lock handle. (See “Wing Lock Handle Installation” on page 17-30.)
VERIFICATION METHOD:
The procedure is complete when the component has been replaced and the wing lock handle and wing
lock switch mounting plate are reinstalled.
RELATED INFORMATION:
"Wing Lock Switch Mounting Plate Removal" on page 17-24
"Wing Lock Switch Mounting Plate Installation" on page 17-26
"Wing Lock Handle Removal" on page 17-28
"Wing Lock Handle Installation" on page 17-30
17.5.1.6 Wing Lock Catch Adjustment
Operate the wing lock handle and verify correct function. The initial handle pull out force from the
stowed and locked position should be about 7 lb
f
. If not, then the wing lock catch may need to be
adjusted using the procedure below.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
14—Wing
Consumables
LOCTITE
®
243™
