Layout Checklist
RTC
General
Guidelines
• RTC LEAD length = 0.25" Max.
• Minimize capacitance between RTCX1 and
RTCX2.
• Put GND plane underneath Crystal
components.
• Don’t route switching signals under the
external components (unless on other side of
board).
USB
General
Guidelines
• Route all traces over continuous planes
(GND) with no interruptions. Avoid crossing
over anti-etch if possible. Crossing over anti-
etch (plane splits) increases inductance and
radiation levels by forcing a greater loop
area. Likewise, avoid changing layers with
high-speed traces. (Applies to USB signals,
high-speed clocks, as well as slower signals
that might be coupling to them.)
• Keep traces at least 50 mils away from the
edge of the reference ground plane. This
helps prevent the coupling of the signal onto
adjacent wires, and helps prevent free
radiation of the signal from the edge of the
PCB.
• Maintain parallelism between USB
differential signals with the trace spacing
needed to achieve 90
Ω differential
impedance. (Recommended: 5 on 6 spacing
with 4-layer 4.5 mil prepreg stackup).
• Minimize the length of high-speed clock and
periodic signal traces that run parallel to
USB signal lines to minimize crosstalk. The
minimum recommended spacing to clock
signals is 20 mils, though it is recommended
to keep clocks and PCI traces at least
50 mils from the USB differential pairs if
possible.
• Use 20 mil minimum spacing between USB
signal pairs and other signal traces. This
helps to prevent crosstalk.
• USB signal pair traces should be trace
length matched. Max trace length mismatch
between USB signal pair (such as USBP2P
and USBP2N) should be no greater than
150 mils.
• No termination resistors needed for USB.
ICH3-S has internal 15 k
Ω resistors.
• 47 pF parallel capacitors may be placed as
close to the USB connector as possible.
Table 14-3. Intel
®
ICH3-S Layout Checklist (Sheet 4 of 4)
Checklist Items Recommendations Comments
To Next Page
