a. On the legend, tap Scale.

The legend is expanded to display a list of range options, in millimeters.

Figure 154: Occlusal Clearance range options

b. Select the required scale.

c. The occlusal clearance is displayed according to the new scale.

If required, tap to take a screenshot of the occlusal clearance. For more information on capturing

screenshots and adding annotations, see section 9.11.

To display the occlusal clearance from the Viewer:

In the Viewer, tap .

2. Select the arch for which to display the occlusal clearance.

The clearance between the opposing teeth is displayed, as well as a legend displaying the scale, in millimeters.

iTero Element® 5D Plus User manual
