Rear view of the scanner

A Wand connector

B Diagnostics panel

(for Support purposes only)

C Upper handle

D New-sleeve basket

Figure 2: Rear view of the scanner

1.3.1 iTero Element 5D Plus wand

A Protective sleeve

B Touchpad

C Side buttons: Scan, on/off,

touchpad activation

D Vent cover

E Air vents

F Detachable wand cable with

USB connector

Figure 3: iTero Element 5D Plus wand

Note: In order to protect the wand cable if too much pulling force is applied, the cable cap is designed to detach from

the wand. If this happens, gently reattach it.
