Scan setting Scan options

Highlight recommended

scanning range check box

Select this check box to highlight only the scanning range on the

navigation controls.

Figure 54: Only scanning range is highlighted

Additional Scan Feedback Select the relevant check boxes to display areas of missing anatomy

while scanning, as described in section 4.5.3.1.

l Orthodontic

l Restorative

Tap to save the changes and return to the Settings window.
