Figure 186: Wipe the optical surface of the wand with IPA
3. Wait until the optical surface dries (approximately 5–10 seconds).
4. Remove any residue from the optical surface using a dry lint-free wipe.
10.2.3 Drying – wand body
Air-dry the disinfected wand at room temperature.
10.2.4 Storage and maintenance
1. Visually inspect the wand for any noticeable damage, for example, deterioration such as corrosion, discoloration,
pitting, or cracks. Pay special attention to the optical surface, making sure it remains clean.
Do not use the wand if any damage is detected. Please contact iTero Support for further
instructions.
2. Inspect the vent cover for noticeable damage, and check that it fits securely on the wand. If the vent cover is
damaged or you are unable to secure it in place, replace it with one of the spare vent covers that were shipped
with the system. For more information on replacing the vent cover, see section 10.2.4.1 below.
Note: When you replace the vent cover, please order an additional vent cover to ensure that you have a spare if
needed.
3. Place the blue protective sleeve on the wand tip.
4. Place the wand in the cleaned and disinfected cradle, as described in section 10.3, below.
10.2.4.1 Removing and replacing the wand vent cover
1. Remove the protective sleeve from the wand.
2. Press both dimples on the wand vent cover to release the locking snaps, and then pull the vent cover towards the
tip of the wand and gently remove it.
