iTero Element 5D Plus - Figure 163: die Separation Tool Options; Figure 164: Scan Is Displayed in Low Resolution

To Next Page

To Previous Page

To create the die separation manually:

In the View window, tap the Die Separation tool .

The tool expands to show the following options:

Figure 163: Die Separation tool options

Tap and mark the whole segment with your finger.

The scan is displayed in low resolution.

Figure 164: Scan is displayed in low resolution

iTero Element® 5D Plus User manual
