11.6.23.12Error22-16(emergencycode7305h)
Cause: Channel 1 Initialization, SSI: 'SingleTurn' from parameter (544) ENC_CH1_
SingleT
Suggested steps:
Change the input of the singleturn bits of the parameter.
Initializationencoder
channel
l Thisisprobablyaproblemofthe
parameterization!
l Inanycaselookatinitoutputsinthemessage
windowoftheDriveManager.
11.6.23.13Error22-17(emergencycode7305h)
Cause: Channel 1 Initialization, SSI: parity error, position data from encoder
Suggested steps:
Initializationencoder
channel1
l Errorduringtheinitializationroutinesof
encoderchannel1.
l Inanycaselookatinitoutputsinthemessage
windowoftheDriveManager.
l Themostcommoncauseoferroristhewiring
totheencoder.
ID No.: 0842.26B.5-01Date: 09.2020
ServoOne- Device Help
396
11 Alarms & warnings
11.6.23.14Error22-20(emergencycode7305h)
Cause: Channel 1 Initialization, SSI: encoder monitoring
Suggested steps:
Check whether the encoder is correctly connected
Initializationencoder
channel1
l Errorduringtheinitializationroutinesof
encoderchannel1.
l Inanycaselookatinitoutputsinthemessage
windowoftheDriveManager.
l Themostcommoncauseoferroristhewiring
totheencoder.
11.6.23.15Error22-22(emergencycode7305h)
Cause: Channel 1 Initialization, HIPERFACE: common error
Suggested steps:
Group error --> look at message window of the DriveManager
Initializationencoder
channel1
l Errorduringtheinitializationroutinesof
encoderchannel1.
l Inanycaselookatinitoutputsinthemessage
windowoftheDriveManager.
l Themostcommoncauseoferroristhewiring
totheencoder.
