KLM MD-11 - Page 115

MD-11 Flight Crew Operations Manual
k
Aircraft General -
Controls and Displays
Agen.30.25
Lower Cargo Doors - Center
DB1-2-1653
CONTROL PANEL
VIEWPORT
DOOR LATCH MANUAL DRIVE FITTING
VENT
DOOR
GREEN STRIPE
ORANGE RECTANGLE
READY TO
LOCK LIGHT
NOTE: Standard 72 inch door shown.
Optional 104 inch door has 4 viewports.
DOOR
ON
OFF
OFF
OFF
BRAKING
G
G
OP E N
STOP
CLOSE
POWER & LTS
ON
W
DOOR
BULKHEAD
CARGO
CARGO
AFT
FWD
ROLLER SELECT
1
2
3
4
5
6
7
8
9
10
GUIDE
BRAKE
HOLD SWITCH IN
CLOSED POSI TION
UNTIL THE ABOVE
LIGHT COMES ON
POWER
AVAIL
CAUTION
DO NOT FORCE HANDLE
IF HANDLE WILL NOT OPERATE
RESTORE POWER TO DOOR AND
HOLD DOOR CONTROL SWITCH
TO DOOR CLOSE POSITION FOR
ADDITIONAL THREE SECONDS
MOVE HANDLE TO CLOSE POSITION
CAUTION
ENGAGED
BE SURE LOCKPINS
CHECK BOTH
VIEWPORTS
CLOSE
OPEN
CAUTION:
AFTER CLOSING
LOCK LATCHES
CAUTION:
BEFORE OPENING
RELEASE LATCHES
LOCK PIN ENGAGED
SYSTEM SAFE
LOCK PIN
NOT ENGAGED
SYSTEM UNSAFE
UNLOCK
MANUAL OPERATION
WARNING:
DOOR MAY SPRING OPEN
PRIOR TO MANUALLY UNLATCHING,
MANUALLY CRANK DOOR ACTUATOR
TO THE FULLY CLOSED POSITION.
DO NOT ATTEMPT TO PRY DOOR
OPEN, OR OPEN DOOR ELECTRICALLY
IF DOOR IS COVERED WITH ICE.
DO NOT USE POWER TOOLS.
TO UNLOCK AND UNLATCH DOOR:
1. PLACE VENT DOOR HANDLE IN
OPEN POSITION.
2. TURN ACTUATOR DRIVE UNTIL
LATCHES ARE OPEN.
TO LATCH AND LOCK DOOR:
1. TURN ACTUATOR DRIVE UNTIL
VENT DOOR HANDLE CAN BE
CLOSED.
LOCK
DOOR ACTUATOR
MANUAL DRIVE FITTING
VENT DOOR/
LATCH HANDLE
October 02, 2006
