 DO NOT shake the cutter while it is operating.
 DO NOT cut any materials that have staples or other embellishments attached.
 DO NOT touch the cutter with a magnet.
 DO NOT allow small items to fall into the cutter.
 TURN OFF the cutter when not in use.
1.04 Parts of the Zing
Front
 Blade Carriage: Moves the Blade Holder Seat left and right
 Blade Holder Seat (Jaw): Holds the blade holder, test pen, and other tools
 Cutting Strip: Protects blade from cutting metal beneath
 Front Screw: Locks blade holder, test pen, and other tools into blade holder seat
 Limit Switches: Provide a buffer between blade carriage and end cap
 Mat/Material Guides: Keeps cutting mat aligned during cutting
 Pinch Wheels: Grip mat or material so that grit shaft (beneath) will feed mat or material in and out
 Pinch Wheel Levers: Lift pinch wheels up and down for loading of mat or material
 Power Button: Turns cutter on or off
 Press Rings: Help keep material from lifting during cutting
Back
Left
End
Cap
Power Button
Blade Carriage
Blade Holder Seat
(Jaw) and Front Screw
Pinch Wheel:
One on each side
Cutting Strip
Power Port
USB Port
Limit Switch:
One on each side
Mat/Material Guide:
One on each side
Press Ring:
Total of 3
Right
End
Cap
Pinch Wheel Lever:
One on each side
