2WA/2NJ/2RK-1
8-40
YC8 4 GND - - Ground
5 EXIT_PAPER_SE
NS
O DC0V/3.3V Eject sensor: On/Off
6 EXIT_FEED_SEN
S
O DC0V/3.3V Reversing sensor: On/Off
7 EX_MOT_REM I DC0V/3.3V Eject motor remote signal
8 EX_MOT_PH I DC0V/3.3V Eject motor excitation switching signal
9 EX_MOT_CLK I DC0V/
3.3V(pulse)
Eject motor clock signal
10 EX_MOT_PD I DC0V/3.3V Eject motor current control signal
11 GND - - Ground
12 DEVE_SHUTTER O DC3.3V Developer shutter detection signal
13 DLP_FAN_H I DC0V/3.3V Developer fan motor (full speed): On/Off
14 DLP_FAN_L I DC0V/3.3V Developer fan motor (half speed): On/Off
15 THOP_MOT_DIR I DC0V/3.3V Toner hopper motor rotation direction con-
trol signal K
16 THOP_MOT_RE
M
I DC0V/3.3V Toner hopper motor remote signal K
17 ENCODE_BK O DC0V/
3.3V(pulse)
Screw sensor K
18 THOP_BK O DC0V/3.3V Toner hopper sensor K
YC9 1 SB_MOT_B/ O DC0V/24V Reversing motor drive output
2 SB_MOT_A/ O DC0V/24V Reversing motor drive output
3 SB_MOT_B O DC0V/24V Reversing motor drive output
4 SB_MOT_A O DC0V/24V Reversing motor drive output
5 EX_MOT_B/ O DC0V/24V Eject motor drive output
6 EX_MOT_A/ O DC0V/24V Eject motor drive output
7 EX_MOT_B O DC0V/24V Eject motor drive output
8 EX_MOT_A O DC0V/24V Eject motor drive output
9 GND - - Ground
10 EXIT_FEED_SEN
S
I DC0V/3.3V Reversing sensor: On/Off
11 +5V2 O DC5V DC5V power output
12 GND - - Ground
13 EXIT_PAPER_SE
NS
I DC0V/3.3V Eject sensor: On/Off
14 +5V2 O DC5V DC5V power output
15 +24V3 O DC24V DC24V power output
Connec-
tor
Pin Signal I/O Voltage Description
