Kyocera TASKalfa 8002i

2WA/2NJ/2RK-1
8-41
YC9 16 JUNC_SOL_REM
_O
O DC0V/24V Feedshift solenoid absorption signal
17 JUNC_SOL__RE
T_O
O DC0V/24V Feedshift solenoid retention signal
YC10 1 +24V3 O DC24V DC24V power output
2 DRUM_AIR_FAN O DC0V/24V Developer fan motor drive
3 +24V3 O DC24V DC24V power output
4 DRUM_DLP_FAN
_BK
O DC0V/24V Developer fan motor drive
5 THOP_MOT_BK_
CCW
O DC0V/24V Toner hopper motor control signal(K)
6 THOP_MOT_BK_
CW
O DC0V/24V Toner hopper motor control signal(K)
7 GND - - Ground
8 THOP_Bk I DC0V/3.3V Toner hopper sensor K
9 +5V2 O DC5V DC5V power output
10 GND - - Ground
11 ENCODE_Bk I DC0V/3.3V Screw sensor K
12 +5V2 O DC5V DC5V power output
13 GND - - Ground
14 DEVE_SHUTTER I DC0V/3.3V Developer shutter detection signal
15 +5V2 O DC5V DC5V power output
16 GND - - Ground
17 +24V3 O DC24V DC24V power output
18 WTNR_MOT_FG I DC0V/3.3V Waste toner motor alarm signal
19 WTNR_MOT_CL
K
O DC0V/3.3V Waste toner motor clock signal
20 WTNR_MOT_DIR O DC0V/3.3V Waste toner motor rotation direction con-
trol signal
YC11 1 IH_CORE B/ O DC0V/24V IH core motor drive
2 IH_CORE B O DC0V/24V IH core motor drive
3 IH_CORE A O DC0V/24V IH core motor drive
4 IH_CORE A/ O DC0V/24V IH core motor drive
5 GND - - Ground
6 IH_CORE_SENS I DC0V/3.3V IH core sensor: On/Off
7 +5V2 O DC5V DC5V power output
Connec-
tor
Pin Signal I/O Voltage Description
